Exclusive Features
- Heavy Duty Galvanized Finish on All Steel Frame Components for Maximum Strength & Long Life
- All Pre-Drilled, Easy Bolt Together Assembly
- Ratchet Straps for a Drum Tight Fit
- Wind Brace Support on each Side
- Complete Anchoring System Included
- 10oz., CPAI-84 Polyethylene Fabric Backed Cover and Doors
- 290 lbs. Shipped in Two (2) Boxes via Motor Freight
- Average Install time – 2 hours
- Easy Bolt Together Design – All Pre-drilled & Cut
- Wind Brace Support on Both Sides
- Two(2) Double Zipper Doors with Bottom Pockets
- Four(4) Bungee Cord Tie Backs for Doors
- Protective Plastic Tube End Caps – All Open Ends
- Standard Thread Plated Hardware Kit with Retaining Nuts & Protective SS Washers
- Quick Assembly Wrench included
- Heavy Duty Poly Rope for Main Cover Tie Down
- Heavy Duty Grommets on Cover & Doors
- Two Box Shipment – easily unloaded and transported &(shown right)
- Average Install time – 2 hours
Pipe Size
Standard Specifications
- Nominal Size 10’ Wide x 20’ Long x 8’ High
- Arches Six(6) on 48” Spacing 1 5/8” Frame Members
- Standard End Door Size10’ Wide X 6′ High at edge double zipper door each end
-
Available Colors & Exterior Colors: Green or Gray
All Interiors: Bright White Only - Shipping Weight 290 lbs shipped in Two(2) boxes Shipped via Motor Freight
- Pallet Dimensions
- 40″ x 68″ x 15″
- Box Dimensions
- Box 1: 63.5″ Long x 17.5″ Wide x 7.5″ High
- Box 2: 66.5″ Long x 20.5″ Wide x 8.75″ High
- Main Cover
- UV Protected Fabric Backed Poly Material 10 0z. Weight. 24 Mil. thick.
- Fire Retardant Standard
- Main Cover & Doors meet CPAI -84 Section 5
- Anchors
- Six(6) 36” Anchors with U-Bolts & Drive Rod Std.
- Stock Number
- 10x20x08- GA102008HGN (OOS) GA102008HGY GA102008HTN
