Rhino Shelter | 12'Wx20'Lx8'H Portable Livestock Shelter (Animal Run-In) House Style

Roll over image to zoom in Click on image to zoom

Rhino Shelter | 12'Wx20'Lx8'H Portable Livestock Shelter (Animal Run-In) House Style

Color: Green

Ventilation Kit: Yes (+$50)

Price:

$1,250.00

Quantity:

Have questions about this product? Call us at 1-406-671-6595 and our team will be happy to help you choose the right solution for your home.

The Rhino Shelters House-style Run-In shelter is made to protect animals without compromising ventilation. Snow accumulation and waterlogging are avoided by the house-style roof. It takes very little work and equipment to assemble a rhino shelter. The shed's frame is made in a way that eliminates the need for drilling or cutting.

The main cover's fabric, which has a woven backing and heat-welded seams, is CPAI-84 rated and made of UV-resistant, fire-retardant poly. A unique layer known as Inner Black Scrim sits between the outer and inner layers. A coating on this layer keeps sunlight from penetrating the material.

Note: End panels are sold separately and are not part of livestock shelters.

Included

10 oz. Cover
6 Earth Anchor Kit
1 5/8″ Galvanized Steel Frame

Exclusive Features

Heavy Duty Galvanized Finish on All Steel Frame Components for Maximum Strength & Long Life
Easy Bolt Together Design – all Pre-drilled & Cut
Wind Brace Support on Both Sides
Protective Plastic Tube End Caps – All Open Ends
Standard Thread Plated Hardware Kit with Retaining Nuts & Protective SS Washers
Quick Assembly Wrench included
Heavy Duty Poly Rope for Main Cover Tie Down
Heavy Duty Grommets on Cover
Two Box Shipment – easily unloaded and transported
Average Install time – 2 hours

Easy Fit Together Design – all Pre drilled & Cut

Pipe Size

Click here Fabric Details

Click here for Steel Tubing Details

Standard Specifications

Product Size 12′ Wide x 20′ Long x 8′ High
Arches Six(6) on 48″ Spacing 1 5/8″ Frame Members
Available Colors Outer Colors: Forest Green, Grey and Tan
All Interiors: White Only
Shipping Weight 289 lbs shipped in Two(2) boxes Shipped via Motor Freight

Box Dimensions Box 1: 58.5″ Long x 15.5″ Wide x 7″ High
Box 2: 66.5″ Long x 20.5″ Wide x 8.75″ High
Main Cover UV Protected Fabric Backed Poly Material 10 0z. Weight. 24 Mil. thick. Fire Retardant Standard Main Cover meet CPAI -84 Section 5
Anchors Six(6) 36″ Anchors with U-Bolts & Drive Rod Std.
Stock Number LV122008HGN, LV122008HTN

Product Documentation

the product spec sheet

the assembly manual
